Unique Features
S-Tube
All Reinert S-Tube Concrete Pumps include the Hinge Valve as standard equipment. Other standard features include a variable volume piston pump and a convenient remote control cable. Our hoppers are designed with straight walls and minimum corners to allow for easy clean-up and little build-up. An optional radio remote control is available. Select models also include an optional remixer.
Diesel Powered
Reinert trailer-mounted Concrete Pumps are diesel-powered and range from 20 cyph to 60 cyph. These pumps are designed for shotcrete, pea-rock and structural mix pumping. Reinert pumps are ideal for pumping small slabs, multi-story slabs, block-filling, and shotcrete. For the best performance and value in concrete pumps, trust Reinert.
Hinge Valve
Hopper Design
The Reinert S-Tube Concrete and pea-rock pumps are built with our innovative design Hinge Valve. All S-Tube valves have build-up of material that is difficult to clean from the discharge end. The Hinge Valve, when in the open position, gives you access to the inside of the S-Tube. The piston cups are also visible and easy to change. When clean-up and maintenance go faster and easier, you will save time, labor, and money.
Our uniquely designed hopper, engineered with specific angles, facilitates the smooth flow of concrete, minimizing material build-up. This intelligent design allows for quick and effortless clean-up, making it ideal for the demanding industrial environment. With Reinert pumps, save both time and effort while enjoying superior performance and ease of use.
Specifications
XR-536
XR-636
Theoretical Concrete
Output (C.Y.P.H.): 36
Piston Head Pressure: 1100
Maximum Aggregate: 1" minus
Concrete Cylinder Diameter: 5"
Concrete Cylinder Stroke: 36"
Discharge Diameter: 5"
Material Valve: S-Tube
Main Hydraulic Pump: Piston
Hydraulic Tank Capacity: 55 gal
Diesel Engine: 75 HP
Fuel Tank Capacity: 15 gal
Hopper Capacity: 8 cu. ft.
Axle: Single
Tires: 15"
Brakes: Electric
Length: 162"
Width: 70"
Hopper Height: 48"
Weight (dry): 4000 lbs
Theoretical Concrete
Output (C.Y.P.H.): 50
Piston Head Pressure: 800
Maximum Aggregate: 1" minus
Concrete Cylinder Diameter: 6"
Concrete Cylinder Stroke: 36"
Discharge Diameter: 5"
Material Valve: S-Tube
Main Hydraulic Pump: Piston
Hydraulic Tank Capacity: 55 gal
Diesel Engine: 75 HP
Fuel Tank Capacity: 15 gal
Hopper Capacity: 9 cu. ft.
Axle: Single
Tires: 15"
Brakes: Electric
Length: 162"
Width: 70"
Hopper Height: 48"
Weight (dry): 4300 lbs
